- Chassis: Produced by gas welding machines from high resistance steel
ST52 meterials as *I* section in resistance calculation excessive
loading has been considered with robotic welding machine.
Axles: Produced as 4*16 tons capacity, automatic braje adjustment
lever and compliance with european standards.
King Pin: Produced with wrought iron (42 cr Mo4). That’s high resistance to
tension and breaking off compliance with 3, 5’’ or 2’’ SAE/DIN norms
and provides easy replacement posibility with screw connections.
Side Walls and Floor : Floor is checkered steel plate or hardened wood. Side walls
Air Suspension : “Lider” Brand air suspension system.
Brake System :Designed according into the european standards are used on
equipped with automatic brake adjustment brake chambers (30
cylinder), Brake Disk (394x210 mm) axle brakes system. There are
two pieces of replecable protective brake sockets.
Rear Axles 30x30 Service emergency bellows.
Landing Gear: Each has 24 tons double and 50 tons single working capacity
and double speed mechhanical support leg.
Tyre: Tubeless tyre in Lassa or Pirelli Brand.
Electric System: 24 Volt electric systems in accordance to EU regulations.
2-)Single basket spare Wheel carrier producted with aliminium panel
3-)1 piece of fire extungisher cabinet
4-)1 piece of tool cabinet
5-)Stanless steel water tank
6-)1 piece wege
9-)4 Pieces Ro-Ro rings.
